Funktion-One Evolution 6SH
Features:
- Funktion One designed drivers with Neodymium Magnets
- Includes steel mounting yoke
- Optional scrim for discrete appearance
- Passive option available
Description
Found a lower price? Let us know
Funktion-One Evolution 6SH Overview
The EVO6SH skeletal loudspeaker is the mid-high section of an Evo6 offering high output and controlled directivity. It can be used in a wide range of applications which include providing additional coverage to an Evo6 system, as the high power mid-high section of a multi-way PA system or in demanding speech based applications such as theatrical voice reinforcement.
Features:
- Funktion One designed drivers with Neodymium Magnets
- Includes steel mounting yoke
- Optional scrim for discrete appearance
- Passive option available
| Driver |
Operating  Band | Sensitivity 1W (2.8V) at 1m |
Power |
(AES)
Nominal
  Impedance
10″200Hz – 4kHz112dB (108dB)250W24Ω1.4″4kHz – up114dB (109dB)75W32Ω
Go to  crossover settings
| Frequency Response ± 3dB: | 200Hz – 18kHz |
| Weight: | 20.5kg (45lbs) |
| Nominal Dispersion: | 50° Horizontal x 25° Vertical |
| Connectors: | Industrial sprung terminals
or Speakon NL4 option |
Additional information
| colour | Violet, White, Black, Custom Colours Available |
|---|
