Funktion-One F315



Features

  • Fully horn loaded for high efficiency
  • Advanced loudspeaker driver design
  • Integral Handles
  • Integral M10 flypoints
  • Optional internal studding for suspending with mid-high loudspeakers (specified on order)

Description

Price excludes VAT

Found a lower price? Let us know

Funktion-One F315 Overview

The F315 offers amazingly well-defined mid-bass from a slim-line enclosure; bringing new power, clarity and output to an important yet often neglected area of the frequency spectrum.

Utilising similar bass loading technology to Funktion One’s highly regarded F215 and F218 Mk2s, with a high performance driver specification and an overall tuning for more impact; the F315 delivers outstanding mid/upper bass performance.  Adding the extra 15” driver, compared to a standard F215 Mk2, not only gives 50% more power but the unique complement of 3 drivers to 2 horns unifies this power in an extremely cohesive and coherent manner.  The F315 can be ideally combined with other Funktion One bass enclosures such as the F221, BR221 or BR218 and mid-high enclosures such at the DS210 or EVO range.

  • Fully horn loaded for high efficiency
  • Advanced loudspeaker driver design
  • Integral Handles
  • Integral M10 flypoints
  • Optional internal studding for suspending with mid-high loudspeakers (specified on order)



Driver
Operating

 Band

Sensitivity
(1W at 1m)
Power
(AES)
Nominal

Impedance

3 x 15″ 55 – 250Hz 106dB 1200W 2.7Ω



Frequency Response ± 3dB: 55Hz – 250Hz
Weight: 81kg (178lbs)
Construction: 15mm Birch Ply
Connectors: Speakon NL4

(All drivers on pins 1+/-)







Additional information

colour

Violet, White, Black, Custom Colours Available
